How to Diagnose a Diesel Engine with Low Power: A Step-by-Step Guide for Technicians
Share
Low power complaints are one of the most common issues seen in diesel trucks—and also one of the hardest to diagnose. Whether you're working on a Cummins ISX, Detroit DD15, or a Paccar MX-13, this guide will walk you through the step-by-step process to pinpoint what’s robbing the engine of power using a diesel diagnostic laptop.
1. Check for Active or Inactive Fault Codes
Start with a full scan using your diesel laptop:
-
Look for SPN and FMI codes related to boost pressure, EGR flow, or fuel delivery.
-
Don’t ignore inactive codes—they can point to intermittent issues.
✅ Tip: Use software like Cummins INSITE, JPRO, or CAT ET to get detailed troubleshooting trees.
2. Inspect Fuel Delivery System
Low rail pressure = low power. Check:
-
Fuel rail pressure (FRP) under load
-
Fuel filter restriction sensor readings
-
Lift pump pressure at idle and WOT
⚠️ Low rail pressure with normal command = injector or rail leak.
⚠️ Low command = failed sensor, fuel actuator, or control issue.
3. Evaluate Turbo and Boost Pressure
Live data you want to track:
-
Desired vs. actual boost
-
Turbo VGT position or actuator duty cycle
-
MAP sensor readings
If boost never rises above 10–15 psi under load, you may have:
-
Leaking charge air cooler (CAC)
-
Sticky turbo vanes
-
Failed VGT actuator
4. Run a Cylinder Cutout Test
Use diagnostic software to:
-
Disable one injector at a time and observe RPM drop
-
No drop = weak or dead cylinder
🛠 Weak injectors or compression loss may not throw a code but will rob power.
5. Check for DPF or EGR Restrictions
A clogged exhaust = choking the engine.
-
Monitor DPF delta pressure
-
Track soot load %
-
Look at EGR valve position vs. command
If soot % is stuck high, run a forced regen and watch EGT sensors.
6. Log a Road Test with Live Data
Create a log file while driving:
-
Throttle %
-
Engine load
-
Boost vs. desired
-
FRP vs. desired
-
NOx sensors and EGR flow
Then review the log to find where power drops—on throttle tip-in, under load, or mid-regen.
7. Bonus: Check for Throttle or Torque Derates
Some trucks will reduce torque output silently if:
-
DEF quality is poor
-
NOx sensors are misreporting
-
EGR temp is outside spec
Use parameter view to check if torque limiters are active.
Final Thoughts:
Low power can come from dozens of root causes, but a structured approach and proper diagnostic tools make the difference. Start with codes, verify sensor data, run key tests, and always compare actual vs. commanded values.
